UXG Gateway Fiber (UXG-Fiber)

RM1,576.00

Brand

Quantity

5 unit available

Please input quantity

Desktop 10G independent gateway with integrated 4-port 2.5 GbE switch.

Dimensions

212.8 x 127.6 x 30 mm (8.4 x 5 x 1.2")

Max. WAN Port Count

6

Default WAN Ports

(1) 10G SFP+
(1) 10 GbE RJ45

Port Layout

2.5 GbE RJ45

4
(2.5G/1G/100M/10M)

10 GbE RJ45

1
(10G/2.5G/1G)

10G SFP+

2
(10G/1G)

IDS/IPS Throughput

5 Gbps

Form Factor

Compact desktop

Stateful Firewall

✓

Application-Aware Layer 7 Firewall

✓

DPI & Traffic Identification

✓

Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps)

✓

Content Filtering

✓

Intrusion Prevention (IPS/IDS)

✓

Ad Blocking

✓

IDS/IPS Signatures

55,000+ With CyberSecure

License-Free SD-WAN

✓

Site-to-Site VPN

Site Magic

✓

IPsec

✓

OpenVPN

✓

VPN Server

Teleport Zero-Configuration VPN

✓

WireGuard

✓

OpenVPN

✓

L2TP

✓

VPN Client

OpenVPN

✓

WireGuard

✓

Multi-WAN Load Balancing

✓

Dynamic Routing

OSPF

✓

Advanced QoS

✓

Multicast DNS (mDNS)

✓

Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT)

✓

Integrated RADIUS Server

✓

RADIUS over TLS (RadSec)

✓

Additional Internet Failover with UniFi LTE Backup

✓

Internet Quality and Outage Reporting

✓

MAC Address Table Size

4,000

PoE Budget

30W

Max. PoE Wattage per Port by PSE

PoE+

30W

Voltage Range PoE Mode

50—57V

Max. Power Consumption

25W (Excluding PoE output)

Power Method

DC jack (54V DC/1.1A)

Power Supply

54V DC/1.1A
(Adapter included)

Supported Voltage Range

100—240V AC

Processor

Quad-core ARM® Cortex®-A73 at 2.2 GHz

System Memory

2 GB

Weight

605 g (1.3 lb)

Enclosure Material

Polycarbonate

Management

Ethernet
Bluetooth

LEDs

Ethernet

✓

SFP+

✓

System

✓

Button

(1) Factory-reset

ESD/EMP Protection

Air: ± 8kV, contact: ± 4kV

Ambient Operating Temperature

0 to 40° C (32 to 104° F)

Ambient Operating Humidity

5 to 95% noncondensing

NDAA Compliant

✓

Certifications

CE, FCC, IC, Anatel: 04395-25-08356
